| Performance > | 額度載重Rated load capacity（t) | 0.6 | |
zui大載重Maximum load capacity（t） | 0.8 | ||
斗容Bucket rated capacity（m)3 | 0.3 | ||
卸載高度Dumping height（mm) | 1780 | ||
zui大舉升高度Lifting Height（mm) | 3140 | ||
卸載距離Dumping Reach（mm) | 980 | ||
zui大舉升力Max. Lifting weight（kg） | 600 | ||
zui大崛起力Max. Excavation Force（kn) | 1000 | ||
zui大爬坡度Max. Grade ability | 30° | ||
zui大轉彎角度Max. Turning Angel | 30°±1 | ||
后橋搖擺度數Swing degree of the rear axle | 7° | ||
Dimensions. &.Weight | 總長Overall length（Bucket on Ground position）mm | 3840 | |
斗寬Bucket width（overall width） | 1160 | ||
高度Overall Height(mm) | 2330 | ||
輪距Wheel base(mm) | 850 | ||
zui小離地高度Min Ground Clearance(mm) | 240 | ||
凈重Net Weight（kg) | 1980kg | ||
Battery | 電瓶型號Battery Model No. | 6-EVF-203A | |
電流rated capacity（3hr) | 200Ah | ||
電瓶數No.of battery groups | 12 | ||
電壓Rated Voltage | 72V | ||
工作小時Working hours（h） | 4-5h | ||
Transmission System | 液壓系統Hydraulic System | 馬達型號Motor No. | CBHV |
電壓Voltage | 72V | ||
功率Power | 5000W | ||
排量Displacement（ml/r) | 18 | ||
輪胎Tyres | 型號Type | 26*1200-12 | |
工作壓力working pressure（mpa) | 0.3 | ||
數量Qty | 4 | ||
Steering System | 轉向類型Type of Steering Hydraulic System | 全液壓轉向Full Hydraulic Steering System | |
系統壓力System Pressure（mpa) | 16 | ||
轉向泵Type of Steering Pump | External Gear Pump | ||
轉向油缸孔距Steering Cylinder Bore（mm) | 63 | ||
數量Qty（pc） | 1 | ||
Braking System | 手剎Service Brake | Drum Brake | |
剎車鼓Brake Drum（mm) | 250 | ||
制動Parking Brake | Drum Brake | ||
分流閥Distribution Valve | 型號Model | DL10 | |
類型Type | Triple valve stem | ||
卸載油缸-孔距Dumping Cylinder-Bore | ?80 | ||
舉升油缸-孔距 Lifting Cylinder-Bore | ?63 | ||
Oil Capacity | 液壓油箱容量Hydraulic Oil Tank（L) | 30 | |
剎車油油量Brake Fluid（L) | 0.8 | ||
